24
US I american
PRECISION TOOLS
Drilling mechanism RS130e
Electrical system RS130e
Pos. Description Article no. Quantity
96 Magnet - 1
97 DIN 6797 - M4 611 9 402 1
98 DIN 7984 - M4 x 6 611 9 016 1
99 Front cover 711 3 401 1
100 Magnet switch - 115 V 611 2 574 1
101 Speed controller 611 4 405 1
102 Cables motor switch-magnet switch-plate 611 1 413 1
103 Circuitboard 711 1 405 1
104 Back cover 711 4 408 1
105 Cables capacitor motor 611 3 416 1
106 Motor cable 711 3 420 1
107 Main cable - GB 611 1 410 + 611 1 425 1
107 Main cable - USA 611 1 409 1
Pos. Description Article no. Quantity
55 Sealing washer 711 3 015 1
56 Shaft sealing ring 34x55x9 711 3 017 2
57 Work spindle 711 3 018 1
58 Circlip 55/2 711 3 016 1
59 Feather key B6x6x20 711 3 019 1
60 Grooved ball bearing 6006 2RS 611 3 540 1
61 Connection cooling 611 3 515 1
62 PT screw 50x35 711 2 003 4
63 Gear housing 711 3 014 1
64 T piece 711 4 002 1
65 Cylinder head screw M3x20 711 4 001 2
66 O-ring 36x1.5 711 3 038 1
67 Seeger snap ring SB42 711 3 037 1
68 Spring plunger Ø 6 611 2 531 1
69 Control button 711 3 036 1
70 Grooved ball bearing 6005 2RS 611 3 537 1
71 Adjusting washer 25/35x0.1 711 3 020 1
72 Spindle wheel 611 3 546 1
73 Circlip 24/1.2 611 3 524 1
74 Grooved ball bearing 6000 658 324 236 2
B2 Coupling, cpl. 711 3 021 1
75 Intermediate shaft 1 711 3 022 1
76 Disc spring 28/12.2x1 611 3 550 4
77 Coupling half 611 3 544 1
78 Feather key, hardened A5x5x10 711 3 023 1
79 Coupling wheel 611 4 539 1
80 Thrust washer 2 711 3 026 1
81 Adjusting washer 12x0.5 711 3 025 2
82 Thrust washer 1 711 3 024 1
83 Lock washer 9 611 3 528 1
84 Needle sleeve HK0810 611 1 521 3
85 Needle bearing RNA 4900 611 3 538 1
86 Washer for needle bearing 711 3 030 1
87 Intermediate shaft 3 711 3 028 1
88 Feather key, hardened A5x5x10 711 3 023 1
89 Intermediate wheel 711 3 029 1
90 Gear cluster 1 711 3 027 1
91 Coupling bolts 1 711 3 031 1
92 Hexagon socket screw M4x16 711 3 033 1
93 Sleeve 711 3 032 1
94 Intermediate shaft 2 658 324 247 1
95 Feather key A5x5x28 611 2 517 1
