16
GB I english
PRECISION TOOLS
Pos. Description Article no. Quantity
1 Gasket for gear box 611 1 501 1
2 Conclusion plate 611 1 514 1
3 Gasket 25.0 x 40.0 x 7.0 611 1 515 2
4 Needle bush HK 0810 611 1 521 3
5 Safety ring DIN 471 – 28.0 x 1.5 611 1 524 1
6 Ball bearing 6001-2Z 611 1 525 1
7 Ball bearing 608 2Z 611 1 526 1
8 O-ring 22.0 x 2.5-NBR 611 1 527 1
9 Brush holder compl. 611 1 528 2
10 Thrad groove screw Z M 4 x 12.0 611 1 530 4
11 Screw DIN 7981 3.9 x 60.0 611 1 531 2
12 Screw DIN 7981 4.8 x 38.0 611 1 532 4
13 Spring washer B4 corrugated 611 1 533 4
14 Motor casing 611 2 501 1
15 Motor cover 611 2 502 1
16 Switch 611 2 503 1
17 Bearing sign 611 2 505 1
18 Gear box 611 2 506 1
19 Air connduction ring 611 2 507 1
20 Socket 4.0 x 7.0 x 16.0 611 2 508 1
21 Grease chamber 611 2 513 1
22 Screw DIN 912 M 4 x 20.0 611 2 514 1
23 Work spindle 611 2 516 1
24 Feather key A 5.0 x 5.0 x 28.0 611 2 517 1
25 Feather key A 5.0 x 5.0 x 12.0 DIN 6885 611 2 518 1
26 Safety ring DIN 471 – 11.0 x 1.0 611 2 519 1
27 Spindle wheel 45 Z 611 2 520 1
28 Feather key 15.0 x 22.0 x 0.2 611 2 521 1
29 Stud wheel 34 Z 611 2 522 1
30 Shaft for cluster gear 13 Z 611 2 523 1
31 Groove ball bearing SKF 608 611 2 524 1
32 Safety ring DIN 471 – 15.0 x 1.0 611 2 525 1
33 Coupling pin 611 2 526 1
34 Cluster gear 34/40 Z 611 2 527 1
35 Shaft with 2 pinion 611 2 528 1
36 Groove ball bearing SKF 61904-2 RS1 611 2 529 1
37 Groove ball bearing SKF 6203-2 RS1 611 2 530 1
38 Pressure device 6.0 x 7.0 611 2 531 1
39 Carbon brush RS25e 611 2 551 2
40 Rotor 611 2 552 1
41 Circuitboard 611 2 553 1
42 Pole ring 611 2 554 1
43 Cylindrical pin DIN 7 4.0 x 12.0 611 3 215 1
44 Screw DIN 7981 3.9 x 50.0 611 3 504 4
45 Spring pressure device M 8 x 16.0 611 3 520 1
Pos. Description Article no. Quantity
46 Cable pipe 611 1 307 1
47 Spacer 611 1 316 1
48 Plate MF 12 611 1 331 1
49 Magnet 611 2 101 1
50 Prop for cable pipe 611 2 210 1
51 Gear holder 611 2 223 1
52 Screw MF 12 611 2 226 1
53 Solid 611 3 200 1
54 Bearing bowl 611 3 212 2
55 Adapter for handle 611 3 216 1
56 Pinion shaft 611 3 217 1
57 Sledge 611 3 219 1
58 Toothed rack
611 3 222 1
Drilling mechanism RS25e
Drilling unit RS25e
