RUKO RS5e - Spare Parts List Rs 40 E

20
GB I english
PRECISION TOOLS
Pos. Description Article no. Quantity
1 Needle bush HK 0810 611 1 521 3
2 Ball bearing 6001 – 2Z 611 1 525 3
3 Thread groove screw Z M4 x 12.0 611 1 530 4
4 Spring washer B4 corrugated 611 1 533 4
5 Feather key A 5.0 x 5.0 x 28.0 611 2 517 1
6 Safety ring DIN 471 – 11.0 x 1.0 611 2 519 1
7 Feather key 15.0 x 22.0 x 0.2 611 2 521 1
8 Pressure device 6.0 x 7.0 611 2 531 1
9 Motor casing 611 3 501 1
10 Motor cover 611 3 502 1
11 Button 611 3 503 1
12 Screw DIN 7981 3.9 x 50.0 611 3 504 4
13 Bearing sign 611 3 505 1
14 Gear box 611 3 506 1
15 Scew DIN 912 – M4 x 16.0 611 3 507 1
16 Socket 7.0 x 4.0 x 12.0 611 3 508 1
17 Coupling pin 611 3 509 1
18 Screw DIN 7981 – 5.5 x 40.0 611 3 512 4
19 Work spindle Morse taper 3 611 3 516 1
20 Gasket 34.0 x 55.0 x 8.0 DIN 3760 611 3 517 2
21 Conclusion plate 55.0 x 34.1 x 6.0 611 3 518 1
22 Air conduction ring 611 3 519 1
23 Spring pressure device M8 x 16.0 611 3 520 1
24 Cylindrical pin DIN7 5.0 x 16.0 611 3 523 1
25 Safety ring DIN 471 – 24.0 x 1.2 611 3 524 1
26 Palte for needle bearing 611 3 525 1
27 Pressure plate 1 611 3 526 1
28 Pressure plate 2 611 3 527 1
29 Safety ring 9x1 DIN 6799 611 3 528 1
30 Grease chamber 611 3 529 1
31 Gasket for gear box 611 3 530 1
32 Plate 611 3 533 1
33 Ring magnet 611 3 534 1
34 Bearing cover 611 3 535 1
35 Circuitboard 611 4 533 1
36 Groove ball bearing 6005 2 RS 611 3 537 1
37 Needle bearing RNA 4900 611 3 538 1
38 Coupling disk 611 4 539 1
39 Groove ball bearig 6006 2 RS 611 3 540 1
40 Grove ball bearing 6000 2Z 611 3 541 1
41 Cluster gear 39/25 Z 611 3 542 1
42 Coupling half 611 3 544 1
43 Intermediate shaft 1 13 Z 611 3 545 1
44 Spindle wheel 611 3 546 1
45 Safety ring DIN 472 – 55.0 x 2.0 611 3 547 1
46 Intermediate shaft 3 12 Z 611 3 548 1
47 Stud wheel 1 28 Z 611 3 549 1
48 Disk spring 28.0 x 12.2 x 1.0 611 3 550 4
49 Intermediate shaft 2 12 Z 611 3 551 1
50 Stud wheel 2 31 Z 611 3 552 1
51 Feather key B 6.0 x 6.0 x 20.0 611 3 553 1
52 Sheet metal screw HF 3.9 x 9.5 611 3 554 2
53 Safety ring DIN 472 – 28.0 x 1.2 611 3 555 1
54 Carbon brush 611 4 556 2
55 Brush holder compl. 611 3 557 2
56 Rotor 611 4 531 1
57 Pol ring 611 4 532 1
Drilling mechanism RS40e
