MODEL 82602-F79A-LCD/82602B-F79B-LCD/82604-F82A-LCD/82604B-F82B-LCD
21
It is used for
disinfecting resin
when softener in
regeneration.
Under the Brine & Slow Rinse
status, it can make a part of brine
water electrolyzed, producing
hypochlorous acid to sterilize and
disinfect the resin.
Connector
of salt
shortage
alarm
It is used for
checking whether
the salt is enough in
the brine tank.
When the brine tank is shortage of
salt, the system will give the alarm
and remind user to add the salt in
time.
Remote
handling
connector
Receipt signal to
make the control
rotate to next circle
It is used for on-line inspection
system, PC connection, and realize
automatically or remote controlling
valve.
A. Signal Output Connector
1) Control Solenoid Valve (Set b-01)
① Solenoid Valve on Outlet Controls Water Level in Brine Tank.
Instruction: If system strictly require no hard water flow from outlet in
regeneration cycle (Mainly for no hard water flow out when valve is
switching or valve in backwash or brine drawing positions), a solenoid
valve could be installed on outlet, the wiring refer to Figure 3-1.
Function:
When valve in service status, if soft water tank is short of water,
solenoid valve is open to supply soft water. But if water tank has enough
To Next Page
