Runxin RL-R100 User Manual

9
8. Usage Illustration
After installing the device and setting the relevant parameters, please conduct the trial running as
follows:
※Fill the brine tank with the planned regeneration salt and the water（Refer to the below table）,
making the brine is saturated (26%). Then start the device (This step is necessary only for the situation
that the device is put into use for the first time.)
Resin Tank
0713
0717
0815
0817
0917
1017
0835
0935
1035
1044
Water (L)
3
4
4.5
5
6
7
9
10
13.5
15
※Switch on power. Press and go in the Backwash status. Slowly open the inlet valve to 1/4
position (Avoiding opening the valve too quickly to damage the device and make the resin run off). At this
moment, you can hear the sound of air-out from the drain pipeline. After all air is out of pipeline, then
open inlet valve completely and conducting 2～3 minutes backwash, cleaning the foreign materials in
the resin tank until the outlet water is clean.
Backwash Status
※Press , turn the status from Backwash to Brine& Slow Rinse. Under this status, the brine will be
absorbed from the brine tank into the resin and the resin is regenerated. After absorbing, the brine valve
will close. The system will still conduct about 15 minute’s slow rinse, wiping off the residual brine. The
whole process will take about 40 minutes to finish.
Brine & Slow Rinse Status
※Press and turn into Brine Refill status. The brine tank will be refilled with water to dissolve the
02:40:25
Water System
Brine & Slow Rinse…
Up-flow
Remaining: 40 min.
02:08:00
Water System
Back Washing…
Remaining: 3 min.
