10
TURNTABLE INSTALLATION
a. Never place the glass turntable upside down.
The glass turntable movement should never be
restricted.
b. Both glass turntable and turntable ring
assembly must always be used during cooking.
c. All food and containers of food are always
placed on the glass turntable for cooking.
d. Do not use the microwave if the glass
turntable or turntable ring assembly cracks or
breaks. Contact Customer Service.
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as
dents or a broken door. Do not install if oven is damaged in any way.
Cabinet: Remove any protective lm found on the microwave oven cabinet and control panel
surfaces. Do not remove the light brown Mica cover that is attached to the inside of the oven
cavity. This is required to protect the magnetron.
INSTALLATION
1. Select a level surface that provides enough
open space for the intake and/or outlet
vents.
2. The minimum installation height is 85cm.
3. The rear surface of the appliance shall be
placed against a wall.
4. A minimum clearance of 30cm is required
above the oven.
5. A minimum clearance of 20cm is required
between the oven and any adjacent walls.
6. Do not remove the legs from the bottom of
the oven.
7. Blocking the intake and/or outlet vents can
damage the oven.
8. Place the oven as far away from radios and television sets as possible. Operation of
microwave oven may cause interference to your radio or TV reception.
9. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is
the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cook top or other heat-producing appliance.
If installed near or over a heat source, the oven could be damaged and the warranty
would be void. The oven is designed for bench-top use only and must not be placed in a
cabinet.
Hub underside
Glasstray
Turntableringassembly
Turntableshaft
cm
cm
min
cm
cm
