Introduction
Congratulations on the purchase of your new RYCOM Cable, Pipe and Fault Locator. The
8878 Series is specially designed to detect buried power cables, CATV cables, gas and water
pipes, sewer lines, telephone cables, fiber optic cables with sheath.
Warning
The 8878 is designed to detect the electromagnetic field emitted from buried metallic
utilities. There are buried cables, pipes, and utilities this instrument cannot detect.
LOCATING is not an exact science. The only way to be sure of the existence, location
or depth of buried utilities is to expose the utility.
DISCLAIMER OF LIABILITY
RYCOM SHALL NOT BE LIABLE TO DISTRIBUTOR, RESELLER, OR ANY OTHER PER-
SON FOR ANY INCIDENTAL, INDIRECT, SPECIAL, EXEMPLARY OR CONSEQUENTIAL
DAMAGES, OR INJURY OF ANY TYPE WHATSOEVER, AND CAUSED DIRECTLY OR
INDIRECTLY BY PRODUCTS SOLD OR SUPPLIED BY RYCOM INSTRUMENTS, INC..
The T
RANSMITTER applies a tracing signal onto a cable or pipe. The RECEIVER detects the trac-
ing signal. You can locate the relative position of the buried pipe or cable by following the trac-
ing signal.
8879 Cable, Pipe and Fault Locator
R
ECEIVER 001-00216-00
TRANSMITTER (NON-RECHARGEABLE) 001-00217-01
TRANSMITTER (RECHARGEABLE) 001-00217-00
USER’S MANUAL 030-00078-00
TRAINING VIDEO 035-00001-00
RED/BLACK C
ORD(LARGE CLAMP) 151-00052-00
G
ROUND ROD 211-00015-01
AC C
HARGER 750-00014-00
AC CHARGER 230 VOLT
750-00003-00
(R
ECHARGEABLE TRANSMITTER
ONLY)
DC C
HARGER 750-00016-00
6 - DURACELL “C” BATTERIES 770-00022-00
8 - DURACELL “D” BATTERIES 770-00023-00
(N
ON-RECHARGEABLE TRANSMITTER ONLY)
Prepare for Use
Unpack your new RYCOM locator. Make sure there is no shipping damage and all the parts are included.
Locate the battery compartment on the back of the “head” of the R
ECEIVER. Open the compartment using
a phillips screwdriver. Install the six Duracell “C” batteries as marked.
Locate the battery compartment on the bottom of the T
RANSMITTER. Remove the two screws from the bat-
tery compartment door. Install the eight Duracell “D” batteries as marked.
Note: For longer battery life and reliable operation under adverse conditions, use only Duracell alkaline bat-
teries.
WARNING
LETHAL VOLTAGES PRESENT
AT THE OUTPUT OF THE TRANSMITTER
8879 Accessories
H
ARD INDUCTIVE
CLAMP(82KHZ) 100-00134-00
H
ARD INDUCTIVE CLAMP (82KHZ/8KHZ) 100-00193-00
FLEXICOUPLER (815HZ/ 82KHZ 100-00110-00
F
LEXICOUPLER (82KHZ/ 8KHZ) 100-00166-00
G
ROUND RETURN PROBE 001-00087-01
815HZ SEWER SONDE 001-00116-00
8K SEWER SONDE 001-00116-02
815HZ DUCT PROOFING SONDE 001-00144-00
H
EADSET
743-00013-00
