Ryobi A25RT02 Repair Sheet

RYOBI ROUTER TABLE – MODEL NUMBER A25RT02
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 9002780019 * CARRIAGE BOLT (1/4-20 x 1 3/4 in.) ................6
2 9002800005 LEFT SLIDING FENCE FACE ............................1
3 9002800004 JOINING FENCE ...............................................1
4 9002800003 FENCE ..............................................................1
5 9002800017 T-TRACK (LEFT SIDE) .......................................1
6 9002780021 LOCK KNOB WASHER ..................................... 7
7 9002780022 LARGE LOCK KNOB ........................................2
8 9002780032 SMALL LOCK KNOB W/SHOULDER ...............5
9 9002800019 T-TRACK SCREW (10-24 x 5/8 in.) ...................8
10 9002780033 SMALL LOCK KNOB ........................................2
11 9002800010 CUTTER/BIT GUARD ........................................1
12 9002780040 FLAT WASHER ..................................................4
13 9002780037 SHORT HINGE PIN ...........................................1
14 9002780039 E-RING ..............................................................4
15 9002780038 LONG HINGE PIN .............................................1
16 9002780036 CUTTER GUARD BRACKET .............................1
17 9002800018 T-TRACK (RIGHT SIDE) .....................................1
18 9002800016 FEATHERBOARD CARRIAGE BOLT
(1/4. x 20 x 1/4 in.) ............................................2
19 9002800009 FEATHERBOARD ..............................................1
20 9002800025 ROUTER TABLE TOP ........................................ 1
21 9002780055 * INSERT PLATE SCREW (10-24 x 3/4 in.) .......... 2
22 9002800020 T-TRACK NUT (10-24) .......................................8
23 9002780034 * HEX BOLT (1/4-20 x 7/8 in.) .............................. 1
24 9002780014 STARTING PIN ..................................................1
25 9002780009 THROAT PLATE-A (1/2 in.) ................................ 1
9002780010 THROAT PLATE-B (1 in.) ...................................1
9002780011 THROAT PLATE-C (1-3/16 in.) ..........................1
9002780012 THROAT PLATE-D (1-1/2 in.) ............................1
9002780013 THROAT PLATE-E (2 in.) ...................................1
26 9002780054 * LEVELING SCREW (1/4-20 x 5/16 in.) .............. 4
27 9002780072 INSERT PLATE (INC. KEY 26) ...........................1
28 9002780006 UNDER TABLE GUARD ....................................2
29 9002780051 WOOD SCREW ............................................... 10
30 9002780005 REAR TABLE LEG (INC. KEY 31) ...................... 2
31 9002780042 RUBBER PAD ....................................................4
32 9002780044 WARNING LABEL (SPANISH/FRENCH) ...........1
33 9002780004 RIGHT FRONT TABLE LEG
(INC. KEY NOS. 31-32) ..................................... 1
34 9002780015 LEG SCREW ...................................................16
35 9002780020 CARRIAGE BOLT WASHER .............................. 6
36 9002780017 * SWITCH BOX NUT (1/4-20 in.) ........................3
37 9002780047 FRONT RAIL .....................................................1
38 9002800007 SWITCH BOX (INC. KEY NOS. 39-40) .............. 1
39 9002780070 SWITCH KEY ....................................................1
40 9002800026 DATA LABEL ......................................................1
41 9002780016 * SWITCH BOX SCREW (1/4-20 x 5/8 in.) ...........3
42 9002780003 LEFT FRONT TABLE LEG
(INC. KEY NOS. 31 AND 43) .............................1
43 9002780043 WARNING LABEL (ENGLISH) ...........................1
44 9002780026 HEX KEY (1/8 in.) ..............................................1
45 9002780023 * SCREW (5/16-18 x 3/4 in.) ............................... 3
46 9002780024 * SCREW (10-24 x 5/8 in.) ..................................3
47 9002780025 * SCREW (10-32 x 5/8 in.) ..................................3
48 9002780073 MITER GAUGE LOCK KNOB ............................1
49 9002780058 MITER GAUGE ..................................................1
50 9002780060 MITER GAUGE SCREW ....................................1
51 9002780062 POINTER ...........................................................1
52 9002780059 BAR ................................................................... 1
53 9002780008 MITER GAUGE ASSEMBLY
(INC. KEY NOS. 6, 48-52) ................................. 1
54 9002800006 RIGHT SLIDING FENCE FACE ..........................1
987000115 OPERATOR’S MANUAL (NOT SHOWN)
03-22-07
(REV:00)
