See this fold-out section for all of the figures
referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes les figures
mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas las figuras
a las que se hace referencia en el manual del operador.
F
A
Fig. 1
A - Tool mount (support d’outil, montaje de la herramienta)
B - Lower shaft (arbre inférieur, barra inferior)
C- Nut (écrou, tuerca)
D - Bolt (boulon, perno)
E - Lock-out trigger (gâchette de verrouillage éteindre, gatillo de seguridad)
F - Handle assembly (assemblage de la poignée, conjunto del mango)
