5
Power
Without battery pack
On
/ Ready to charge battery pack.
Evaluate Hot battery pack Flashing /
When battery pack reaches cooled temperature, charger
begins fast charge mode.
Evaluate Cold battery pack Flashing /
When battery pack reaches warmed temperature, charger
begins fast charge mode.
Evaluate Deeply discharged Flashing /
Charger pre-charges battery until normal voltage is reached,
then begins fast charge mode.
Defective Defective Flashing Flashing Battery pack or charger is defective.
y If the LED status repeats a second time, try charging a different battery.
y If a different battery charges normally, dispose of the defective pack (see maintenance section).
y If a different battery also indicates "defective," the charger may be defective.
Charging Fast charging / Flashing —
Full — /
On
Fast charging is complete; charger maintains charge mode.
Off Off Off Flashing In charging process, battery pack capacity is lower than 25%
Off Off Flashing On In charging process, battery pack capacity is between 25%-50%.
Off Flashing On On In charging process, battery pack capacity is between 50%-75%.
Flashing On On On In charging process, battery pack capacity is between 75%-100%.
On On On On Full charged
Off Off Off Off
One minute after full charge, all LEDs on the battery are off, charger LED is on with
green color.
Ryobi 36 V lithium-ion batteries are designed with features
that protect the lithium-ion cells and maximize battery life.
If the tool stops during use, release the trigger to reset and
resume operation. If the tool still does not work, the battery
needs to be recharged.
WARNING
If at any point during the charging process none of the
LEDs are lit, remove the battery pack from the charger
to avoid damaging the product. Do not insert another
battery. Return the charger and battery to your nearest
service center for service or replacement.
