RYOBI BELT AND DISC SANDER – MODEL NUMBER BD4601
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
Belt and Disc Sander or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
WARNING: Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
60 BD46075 Drive Belt............................................................ 1
61 BD46015 Idler Pulley ......................................................... 1
62 089027001018 Screw (M5 x 25 mm, Pan Hd.) ........................... 3
63 089027001038 Bearing Base ...................................................... 1
64 089027001039 Screw (M6 x 25 mm, Pan Hd.) ........................... 3
65 089027001040 Screw (M8 x 25 mm, Hex Soc. Hd.) ................... 1
66 089027001041 Belt Guard .......................................................... 1
67 089027001042 Square Nut (M8) ................................................. 1
68 BD46076 Drive Pulley ........................................................ 1
69 BD46043 Roll Pin (5 x 8) .................................................... 2
70 BD46044 Tension Plate ...................................................... 1
71 089027001701 Motor Assembly ................................................. 1
72 089027001708 Power Cord w/Label (Inc. Key No. 91) ............... 1
73 089027001043 Dust Collection Port ........................................... 1
74 BD46034 Roll Pin (5 x 10) .................................................. 1
75 089027001044 Belt Frame Support ............................................ 1
76 BD46024 * Sanding Belt (4 in. x 36 in., 80 Grit) ................... 1
77 BD46107 Switch Holder .................................................... 1
78 089027001045 Screw (M2.9 x 8 mm, Pan Hd.) .......................... 2
79 BD46004 Washer (D8) ........................................................ 2
80 089027001046 Screw (M8 x 16 mm, Hex Soc. Hd.) ................... 2
81 089027001905 Miter Scale Label ............................................... 1
82 089027001048 Cord Clamp Plate............................................... 1
83 089027001906 Miter Gage Logo Label ...................................... 1
84 089027001901 Data Label .......................................................... 1
85 089027001703 Miter Gauge Assembly
(Inc. Key Nos. 81 and 83) ................................... 1
86 BD46052 Drive Roller ......................................................... 1
87 BD46026 Idler Roller .......................................................... 1
88 089027001908 Bevel Scale Label .............................................. 1
89 089027001034 Cord Clamp ........................................................ 1
90 089027001909 Do Not Remove Cover Label ............................. 1
91 089027001904 Cordwrap Warning Label
(French and Spanish) ......................................... 1
92 089027001903 Disc Direction and Warning Label ...................... 1
93 089027001902 Belt Direction Label ............................................ 1
94 089027001907 Warning Label (English)...................................... 1
95 089027001910 Position Lock Label ........................................... 1
96 089027001012 Hex Key (M6) ...................................................... 1
97 089027001033 Screw (M4 x 10 mm, Pan Hd.) ........................... 3
98 089027001051 Grounding Tag.................................................... 1
99 BD46027 Spring Washer (D12) .......................................... 4
100 BD46025 Ball Bearing (101Z) ............................................. 4
101 BD46029 Idler Shaft ........................................................... 1
102 089027001011 Drive Shaft ......................................................... 1
Not Shown:
988000299 Operator’s Manual ............................................. 1
