Fig. 6 Fig. 8
Fig. 7
A - Keyless chuck (mandrin sans clé,
portabrocas de apriete sin llave)
B - Unlock (release) (unlock [desserrer], unlock
[desasegurar])
C - Chuck jaws (mors du mandrin, mordazas
del portabrocas)
D - Drill bit (embout, broca)
E - Lock (tighten) (lock [serrer], lock
[asegurar])
RIGHT / CORRECT / FORMA CORRECTA
D
WRONG / INCORRECT / FORMA
INCORRECTA
B
A
D
C
A
A
B
Fig. 11
Fig. 10
Fig. 9
A - Screwdriver (tournevis, destornillador)
A - Mallet (maillet, mazo de goma)
B - Chuck jaws (mors du mandrin, mordazas
del portabrocas)
C - Hex key (clé hexagonale, llave hexagonal)
D - Keyless chuck (mandrin sans clé,
portabrocas de apriete sin llave)
A - Mallet (maillet, mazo de goma)
B - Hex key (clé hexagonale, llave hexagonal)
B
E
A
C
