GENERAL SAFETY RULES
CLASS 1 LED PRODUCT
SPECIAL SAFETY RULES
■ Hold po wer tool b y insulated gripping surfaces,
when performing an operation where the fastener
may contact hid den wiring. Cutting accessory
contacting a «live» wire may make exposed metal
parts of the power tool «live» and could give the
operator an electric shock.
CHARGER SAFETY
■ Do not expose charger to wet or damp conditions.
■ Use of an attachment not recommended or sold by
the battery charger manufacturer may result in a risk
of fire, electric shock, or injuries to person.
■ To reduce risk of damage to charger body and
cord, p ull by charger plug rather than cord when
disconnecting charger.
■ Make sure cord is located so that it will not be stepped
on, tr ipped o ver, or otherwise subjected to damage
and stress.
■ An e xtension cord should not be used unless
absolutely necessar y. Use of improper extension
cord could result in a risk of fire and electric shock.
If extension cord must be used, make sure:
a. That pins on plug of extension cord are the same
number, size and shape as those of plug on charger.
b. That extension cord is properly wired and in good
electrical condition.
■ Do not operate charger with a damaged cord or
plug. If damaged, have it replaced immediately by a
qualified serviceman.
■ Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in any
way; take it to a qualified serviceman.
■ Do not disassemble charger ; take it to a qualified
serviceman when service or repair is required.
Incorrect reassemb ly may result in a risk of electric
shock or fire.
■ To reduce risk of electr ic shock, unplug the charger
from outlet before attempting any maintenance or
cleaning. Turning off controls will not reduce this risk.
■ Disconnect charger from power supply when not in use.
■ Risk of electric shock. Do not touch uninsulated portion
of output connector or uninsulated battery terminal.
■ Save these instructions. Refer to them frequently and
use them to instruct others who may use this unit.
If y ou loan someone this unit, loan them these
instructions also.
SPECIFICATIONS
Motor 4 V DC
Switch Single Speed/Reversible
No load Speed 180 r/min.(RPM)
Clutch 12 Positions
Torque 5 Nm max
Collet 6.35 mm
Weight (included battery) 0.47 kg
Charger Rating
Input 230V-AC ~ 50Hz
Output 4.5V-DC
160 mA
Charge Time 10-12 hours
DESCRIPTION
1. Quick change chuck
2. LED worklight
3. Direction of rotation selector
(forward/reverse/center lock)
4. Switch Trigger
5. Grip zone
6. Charger
7. Red charge light
8. Input jack
9. Charger plug
10. To decrease torque
11. To increase torque
12. Torque adjustment ring
13. Reverse
14. Forward
15. Collet
16. Bit
OPERATION
WARNING
Do not allow familiarity with products to make
you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
