Ryobi JS550L Repair Sheet

RYOBI JIG SAW – MODEL NUMBER JS550L
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
1 511772001 SCROLLING COVER .........................................1
2 640770001 SCROLLING ......................................................
1
3 660206025 * SCREW (M3.5 X 10 mm PAN HD.) ....................
2
4 671142002 SAW BAR GUIDE BUSHING ............................
1
5 301011001 SCROLLING RELEASE KNOB ASSEMBLY .......
1
6 511773001 SCROLLING RELEASE BLOCK ........................
1
7 671146001 SPRING .............................................................
1
8 680436006 WASHER ...........................................................
1
9 300306016 HEAT SINK ASSEMBLY ....................................1
10 630845001 SLIDE GUIDE PLATE ........................................1
11 680899001 BEARING SLEEVE .............................................1
12 550427001 WASHER ...........................................................1
13 671038001 BEARING SLEEVE .............................................1
14 631303001 SAW BAR SLIDE BRACKET .............................1
15 631304001 CROSS SLIDE BRACKET ..................................
1
16 690072002 SPRING PIN .....................................................2
17 690072003 SPRING PIN ......................................................2
18 300877007 SAW BAR ..........................................................1
19 691966001 COIL SPRING ...................................................1
20 690377003 LINKAGE ARM (RIGHT SCM440) ......................1
21 511826003 BLADE CLAMP LEVER ......................................1
22 671318001 ROLLER .............................................................1
23 690377004 LINKAGE ARM (LEFT SCM440) ........................1
24 671319001 E-RING ..............................................................2
25 691965001 COIL SPRING ....................................................1
26 301007002 SAW BAR & BLADE CLAMP ASSEMBLY
(INC. KEY NOS. 18-25) ......................................
1
