RYOBI JIG SAW – MODEL NUMBER JS550L
5
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
1 301124001 KNOB BOLT ASSEMBLY ..............................................................................................1
2 671143001 PIN STEEL
....................................................................................................................1
3 300577015 BLADE GUIDE ASSEMBLY ..........................................................................................1
4 631082001 LINK ROD ......................................................................................................................1
5 660213008 * SCREW (M4 X 10 mm FLAT HD.) ..................................................................................6
6 631109001 BASE COVER ................................................................................................................1
7 660176006 * SCREW (M4 X 8 mm) ....................................................................................................1
8 631083001 FIX NUT (M5) .................................................................................................................1
9 671150001 ADJUSTABLE PAD ........................................................................................................1
10 640783001 DIE CASTING BASE ......................................................................................................1
11 301010001
BASE TOOL-LESS LEVER ASSEMBLY
............................................................................1
12 678050001 FLAT WASHER ..............................................................................................................1
13 301008001 FIX WEDGE ASSEMBLY ...............................................................................................1
To Next Page
