Ryobi LCDI1402 User Manual

1. Keyless chuck
2. Torque adjustment ring
3. Quick mode selector
4. Two-speed gear train
5 . Rotation selector (forward/reverse/center lock)
6. Bit storage
7. Trigger switch
8. Mag Tray™
9. Battery pack
10. Latches
11. Depress latches to release battery pack
12. Reverse
13. Forward
14. Chuck jaws
15. Lock (tighten)
16. Unlock (release)
17. Low speed
18. High speed
19. Drive mode
20. Drill mode
21. Hammer mode
22. To increase torque
23. To decrease torque
24. Bit
25. Screws
26. Bit holder
27. Drill bit
28. Chuck sleeve

1
2
3 4
5
7
9
6
8
10
11
9
8
7
26
25
24
Fig. 1 Fig. 2

Ryobi LCDI1402 Specifications

General

Brand	Ryobi
Model	LCDI1402
Category	Drill
Language	English
