Ryobi LLCDI1802 - Page 2

1. Keyless chuck
2. Torque adjustment ring
3. Quick mode selector
4. Two-speed gear train
5. Rotation selector (forward/reverse/center lock)
6. Bit storage
7. Switch trigger
8. Battery pack (Not included)
9. Latches
10. Depress latches to release battery pack
11. Reverse
12. Forward
13. Chuck jaws
14. Lock (tighten)
15. Unlock (release)
16. Low speed
17. High speed
18. Drive mode
19. Drill mode
20. Hammer mode
21. To increase torque
22. To decrease torque
23. Bit
24. Bit holder
25. Chuck sleeve
26. Drill bit
DESCRIPTION
Fig. 1
1
2
3
4
23
6
7
8
5
