14
English (Original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Front Handle Assembly
Operator’s Manual
Charger (For RLT1830Li only)
Battery (For RLT1830Li only)
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from
the product when assembling parts.
DESCRIPTION
Figure 1
1. Switch trigger
2. GripZone™ overmold
3. Lock-out button
4. Adjustable front handle
5. Rotating rear handle
6. Telescoping shaft
7. 3-Position pivoting head
8. Edger guide
Figure 2
10. Slide over head and turn counterclockwise
11. Line cut-off blade
Figure 3
12. Screw holes
13. Screws
Figure 4
1. Switch trigger
3. Lock-out button
Figure 5
14. Latches
Figure 6
6. Telescoping shaft
15. Telescoping shaft coupler
Figure 7
16. Knob
Figure 8
17. Pivot button
Figure 11
18. Line release button
19. String
Figure 12
8. Edger guide
11. Line cut-off blade
Figure 13
5. Rotating rear handle
20. Edging coupler
Figure 15
21. Spool cover
22. Spool
23. Spool cover lock buttons
24. Slots
25. Eyelet
Figure 16
22. Spool
26. Hole
ATTACHING GRASS DEFLECTOR
See Figure 2 - 3.
WARNING
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
Fit the grass deflector into the slots on trimmer head.
Line up the screw holes in the grass deflector with the
holes in the trimmer head.
Install supplied screws and tighten by turning
clockwise with a phillips screwdriver.
OPERATION
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a
To Next Page
