Ryobi P202 - Page 30

12
C
B
E
A
D
Fig. 7
Fig. 8
A - Keyless chuck (mandrin sans clé,
portabrocas de apriete sin llave)
B - Unlock (release) [unlock (desserer), unlock
(desasegurar)]
C - Chuck jaws (mors du mandrin, mordazas
del portabrocas)
D - Drill bit (embout, broca)
E - Lock (tighten) [lock (serrer), lock
(asegurar)]
Fig. 9
WRONG / INCORRECT /
FORMA INCORRECTA
LEVEL TOP VIEW / VUE DE DESSUS DE
NIVEAU / VISTA SUPERIOR DE NIVEL
RIGHT / CORRECT / FORMA CORRECTA
A - Hex key (clé hexagonale, llave hexagonal)
B - Chuck jaws (mors du mandrin, mordazas
del portabrocas)
C - Mallet (maillet, mazo)
D - Chuck (mandrin, poortabrocas)
A
B
C
D
A - Screwdriver (tournevis, destornillador)
Fig. 10
A
Fig. 11
A - Hex key (clé hexagonale, llave hexagonal)
B - Mallet (maillet, mazo)
A
B
Fig. 12
