10
Fig. 2
BLADE SHOWN
CORRECT IN SAW BAR
BLADE
BLADE CLAMP
ASSEMBLY
BLADE CLAMP
LOCK / RELEASE LEVER
TO INSTALL /
TO RELEASE
TO LOCK
UNPACKING
This product requires assembly.
n Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
n Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
n Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.
n If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
PACKING LIST
Cordless Reciprocating Saw
Saw Blades (2)
Lanyard (not included in combo)
Operator’s Manual
Warranty Registration Card
WARNING:
If any parts are missing do not operate this tool until the
missing parts are replaced. Failure to do so could result
in possible serious personal injury.
WARNING:
Do not attempt to modify this tool or create accesso-
ries not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
tool when assembling parts.
TO INSTALL SAW BLADE
See Figure 2.
n Remove battery pack.
n Lift blade clamp lock / release lever located on side of
saw.
n Insert saw blade between blade clamp and saw bar.
n Lock blade clamp lever.
n Replace battery pack.
