6
P784
Fig. 1 Fig. 2
A - LED Indicator (témoin DEL, diodos indicadore)
B - Power button (bouton d’alimentation, botón de encendido/
apagado)
C - LED lens (lentille DEL, lentes LED)
A - EVERCHARGE
port (port EVERCHARGE
, puerto
EVERCHARGE
)
B - EVERCHARGE
wall mount adaptor (adaptateur mural
EVERCHARGE
, adaptador de pared EVERCHARGE
)
C - LED indicator (témoin DEL, diodo luminiscente indicador)
D - Handle (poignée, mango)
E - EVERCHARGE
port (port EVERCHARGE
, puerto
EVERCHARGE
)
F - USB port (port USB, puerto USB)
A - Latches (loquets, pestillos)
B - Battery pack (bloc-piles, baterías)
A
B
C
F
B
A
E
D
B
C
A
