Fig. 4
BENT END OF
SILENCER GUARD
OPENING IN REAR
HOUSING
SILENCER GUARD ASSEMBLY
See Figure 4.
1. Remove silencer guard and two screws from the
owner’s kit.
2. Attach the silencer guard to the rear housing.
NOTE: Make sure the bent end of the silencer guard fits
securely into the opening of the rear housing.
3. Using the torque wrench supplied, install the two screws
and tighten securely.
ASSEMBLY
SCREWS
SILENCER
GUARD
REAR HOUSING
TORQUE
WRENCH
