Ryobi RBV254O - Storage Procedures; Disassembling the Unit for Storage

37
STORAGE
1
2
2
3
1
A1
A3
1
A2
STORAGE
1. To stop the engine, toggle the on/off
switch to the “STOP” position.
A1.Twist the vacuum tube assembly
counterclockwise to remove assembly.
A2.Remove the vacuum tube assembly
from the housing outlet.
A3.Press on the raised locking tab, twist
the adaptor counterclockwise, and then
detach the vacuum bag adaptor from the
housing.
