9
Know your product
KNOW YOUR PRODUCT
1
2
3
4
111213 10 9 8 7
17
16
15
14
5
6
19 18
1. Front handle
2. Quick release handle
3. Shoulder/strap pad
4. Cruise control lever
5. Rear handle
6. On/Off trigger
7. Blower/vacuum mode selection lever
8. Bag adaptor
9. Vacuum bag
10. Upper blower tube
11. Lower blower tube
12. High speed nozzle
13. Guide wheels
14. Lower vacuum tube
15. Upper vacuum tube
16. Locking screw
17. Fan cover
18. Sliding lock
19. Locking pin
