EMPTYING THE VAC BAG
1. Remove the battery pack.
Press the latch to unlock and then pull
the battery pack out of the housing.
2. Remove the vacuum bag.
Unhook the vacuum bag from the
lower blower tube. At the rear side of
the vacuum bag opening, unlatch the
locking tab from the bag adaptor and
then remove the vacuum bag.
3. Unzip the vacuum bag and remove its
contents.
