Ryobi RCS1350 User Manual

DESCRIPTION
1. Dust extraction outlet
2. Blade guard retracting lever
3. Lower guard
4. Bevel adjustment knob
5. Upper guard
6. Front handle
7. Rear handle
8. Trigger switch
9. Safety button
10. Cut depth locking lever
11. Spindle lock
12. Hex wrench
13. Parallel guide fence
14. Blade
15. Hex bolt
16. Outer flange
17. Inner flange
DESCRIPTION
Fig. 8
Fig. 1
Please refer to pages 3 - 4 for instructions
Fig. 7
Components list
12
6
13
7
1
2
3
5
4
9
9
8
10
11
Fig. 6
Fig. 4
Fig. 5
16
14
15
17
Fig. 2
12
11
10
Fig. 3

Ryobi RCS1350 Specifications

General

Brand	Ryobi
Model	RCS1350
Category	Saw
Language	English
