Ryobi RGN2500B - KNOW YOUR PRODUCT

Fig 2 Fig 3
Fig 1
1
4
2
3
5
6
7
8
9
1. Carburetor drain screw
2. Oil drainage plug
3. Oil cap/dipstick
4. Circuit breaker
5. Frame handle
6. Recoil starter grip
7. Air filter
8. Fuel cap
9. Fuel tank
10. Oil fill hole
11. Oil cap/dipstick (removed)
12. Fuel valve
13. Fuel valve (on)
14. Fuel valve (off)
15. Choke lever
16. To start (choke closed)
17. To run (choke open)
18. Screw
19. Spark plug
20. Spark plug cap
21. Fuel line
22. Wheel
23. Axle
24. Washer
25. Hitch pin
26. Screws
27. Leg
28. Lock nut
29. Frame handle (folded)
30. Frame handle (unfolded)
KNOW YOUR PRODUCT
