13
Fuel tank volume 3.8 L
Run time (half load) 5 hours
Run time (full load) 3 hours
Generator
Rated Voltage 240 V AC/12 V DC
Rated Amps 6.67 A AC/7.5 A DC
Rated Running Watts 1,600 W
Starting Watts 2,000 W
Rated Frequency 50 Hz
Floating neutral Yes
Noise specifi cations
Uncertainty (dB) 2
Noise level (4m) LpA dB (A) 72
Noise level (7m) LpA dB (A) 67
Noise level LwA dB (A) 82
FEATURES
KNOW YOUR GENERATOR
See Figure 1.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarise yourself with all
operating features and safety rules.
240 V AC RECEPTACLES
Your generator has two single phase, 50 Hz outlets that are
240 Volt AC, 15 Amp receptacles. These can be used for
operating appropriate appliances, electrical lighting, tools,
and motor loads.
AIR FILTERS
The air fi lters help to limit the amount of dirt and dust drawn
into the unit during operation.
AUTO IDLE SWITCH
The auto idle switch is used to control the speed of the
engine and conserve fuel. When the switch is in the ON (I)
position and no appliances are connected to the unit, the
engine will idle. If an appliance is added, the engine speed
will increase to power the item. If the appliance is removed,
the engine will return to idle.
BATTERY CHARGING CABLE
The battery charging cable makes it easy to charge 12 Volt
lead acid batteries with the generator.
NOTE: Only use battery charging cable to charge vented
wet lead acid batteries.
CARRY HANDLES
The generator is equipped with two carry handles for easy
transport. Both handles should be used to carry the generator.
DC CIRCUIT BREAKER
The circuit breaker is provided to protect the generator
against electrical overload.
DC RECEPTACLE
Your generator has a 12 volt, 7.5 Amp DC receptacle for
charging lead acid batteries.
ENGINE/CHOKE LEVER/ON-OFF SWITCH/FUEL
VALVE LEVER
The engine/choke lever/ on-off switch/fuel valve lever is used
when starting, stopping, and running the engine.
FUEL TANK
The fuel tank has a capacity of 3.8 L.
GROUND TERMINAL
The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock.
Consult with a local electrician for grounding requirements
in your area.
LED DISPLAY
LEDs provide feedback to indicate whether the generator
is in use, overloaded, or in need of lubricant.
OIL CAP/DIPSTICK
Remove the oil fi ll cap to check and add oil to the generator
when necessary.
PARALLEL KIT TERMINALS
The non-polarized parallel kit terminals are used with a
parallel kit (sold separately) that will allow generators to
be linked together to increase output.
NOTE: Read and understand the parallel kit’s instructions
prior to use. Kit is for usage with this unit only.
RESET BUTTON
The reset button is used to restore power if an overload
occurs. To restore power, depress the reset button.
RETRACTABLE HANDLE
The generator is equipped with a retractable handle that
can be adjusted for storage and transportation.
STARTER GRIP AND ROPE
The starter grip and rope is used (along with the engine/
