Ryobi RLT36BL - Adjusting the Cutting Width; Changing Cutting Width Settings

14
OPERATION
x2
1
3
2
1
x2
2
406 mm
355 mm
355 mm
406 mm
2
1
1
2
3
ADJUSTING THE CUTTING WIDTH
1. Press the battery latch button, and remove
the battery pack.
2. Loosen the screws on the line cut-off blades.
Remove the blades. Rotate the line cut off
blades 180º.
NOTE: Runtime is increased on 33 cm setting.
3. Install the line cut-off blades into the new
position. Screw the blades onto the guard
to secure.
406 mm
355 mm
