3
Ryobi 26
cc
StRing tRimmeRS
model numbeRS – Ry28100, Ry28120 & Ry28140
18 678008001 Washer .................................................................. 1
19 518949001 Wing Nut ............................................................... 1
20 518696001 Throttle Trigger ...................................................... 1
21 308842004 Throttle and Lead Assembly ................................. 1
22 660925011 Screw (M4 x 8 mm, Torx T.F.) ............................... 1
23 678029002 Hex Nut (M6) ......................................................... 1
24 690694002 Throttle Spring ...................................................... 1
25 940654088 Combustion Warning Label................................... 1
26 940705011 Logo Label ............................................................ 1
27 941788001 Primer Label .......................................................... 1
28 900952011 Air Filter ................................................................. 1
29 940216004 Start Run Label ..................................................... 1
30 941790001 Fuel Tank Warning Label ....................................... 1
31 308045006 Boom Clamp ......................................................... 1
Not Shown:
990000224 Operator’s Manual (RY28100) ............................... 1
990000227 Operator’s Manual (RY28120 and RY28140) ........1
2-5-13
(Rev:01)
1 660563002 Screw (M4 x 20 mm) .............................................4
2 308869002 Control Handle Assembly .....................................1
3 518695001 Trigger Lock ..........................................................1
4 638431001 Strap Hanger ......................................................... 1
5 760700002 Switch (Momentary Contact) ................................1
6 570234002 Rear Handle ..........................................................1
7 870174001 * Spark Plug (Champion RCJ6Y) ............................. 1
8 690140011 Compression Spring .............................................1
9 525105002 Air Box Cover ........................................................ 1
10 310817004 Fuel Cap Assembly (1.5 in. Diameter) ................... 1
11 940734131 Label......................................................................1
12 660697002 Bolt (M6 x 20 mm) ................................................. 1
13 308470013 Upper Boom Assembly ......................................... 1
14 940657034 Warning Decal ....................................................... 1
15 308991001 Front Handle Assembly (Inc. Key Nos. 16-19) ...... 1
16 518738001 Front Handle ......................................................... 1
17 660643008 Bolt (1/4-20 x 40 mm) ........................................... 1
PARTS LIST (FIGURE A)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
