Ryobi RY40050 - Assembly

Page 11 — English
Fig. 2
ATTACHING THE SHOULDER
HARNESS
See Figure 3.
 Connect the latches on the shoulder harness to
the strap hanger on power head.
 Adjust the strap to a comfortable position.
ASSEMBLY
POWER
HEAD
24 VOLT
POWER HEAD
40 VOLT
POWER HEAD
THREADED BASE
CUTTING HEAD
POLE
COLLAR
COLLAR
Fig. 3
LATCH
STRAP HANGER
COLLAR
INTERMEDIATE POLE
MANDATORY POLE
SOCKET
PLUG
PLUG
SOCKET
THREADED BASE
POLE SAW
ATTACHMENT
