Page #5 background imageLoading...
Page #5 background image
v
Fig. 15
A - Blade (lame, hoja)
B - Wrench (clé, llave)
C - Block of wood (pièce de bois, bloque de
madera)
A
B
C
Fig. 14
Fig. 12
Fig. 13
Fig. 17
Fig. 16
TO STORE THE MACHINE
IN THE HORIZONTAL POSITION
POUR REMISER L’ÉQUIPEMENT
EN POSITION HORIZONTALE
PARA GUARDAR LA MÁQUINA
EN POSICIÓN HORIZONTAL
TO STORE THE MACHINE
IN THE VERTICAL POSITION
POUR REMISER L’ÉQUIPEMENT
EN POSITION VERTICALE
PARA GUARDAR LA MÁQUINA
EN POSICIÓN VERTICALE
A - Adaptor (adaptateur, adaptador)
B - Hub (arbre, eje)
C - Blade post (half circle) [tige pour
lame (demi-cercle), puerto de la hoja
(semicircular)]
D - Blade post (round) [tiges pour lame
(ronde), montantes de cuchilla (Redondo)]
E - Blade (lame, hoja)
F - Blade hole (half circle) [trou pour
lame (demi-cercle), orificio de la hoja
(semicircular)]
G - Blade hole (round) [trou pour lame (ronde),
orificio de la hoja (redondo)]
H - Blade insulator (isolant de lame, aislante de
hoja)
I - Spacer (entretoise, separador)
J - Blade nut (écrou de lame, tuerca de la hoja)
K - Shaft (arbre, eje)
15° MAXIMUM
15° MAXIMAL
15° MÁXIMA
K
F
G
D
C
B
E
A
J
I
H
