S.& A.S. MicroZed V3.5 User Manual

With 2
Extensions
Down Collecve

Full Collecve
P +22 V
Biasing voltage from periphery supply – posive side

GND
Biasing voltage from periphery supply – negative side

EC 0 Down 0 Up 0
EC 1 Down 1 Up 1
EC 2 Down 2 Up 2
EC 3 Down 3 Up 3
EC 4 Down 4 Up 4
EC 5 Down 5 Up 5
EC 6 Down 6 Up 6
EC 7 Down 7 Up 7
EC
8 Down 8 Up 8
EC
9 Down 9 Up 9
EC
10 Down 10 Up 10
EC
11 Down 11 Up 11
EC 12 Down 12 Up 12
EC 13 Down 13 Up 13
EC
14 Down 14 Up 14
EC
15 Down 15 -
With 3
Extensions
Down Collecve

Full Collecve
P +22 V
Biasing voltage from periphery supply – posive side

GND
Biasing voltage from periphery supply – negative side

EC 0 Down 0 Up 0
EC 1 Down 1 Up 1
EC 2 Down 2 Up 2
EC 3 Down 3 Up 3
EC 4 Down 4 Up 4
EC 5 Down 5 Up 5
EC 6 Down 6 Up 6
EC 7 Down 7 Up 7
EC 8 Down 8 Up 8
EC 9 Down 9 Up 9
EC 10 Down 10 Up 10
EC 11 Down 11 Up 11
EC 12 Down 12 Up 12
EC 13 Down 13 Up 13
EC 14 Down 14 Up 14
EC 15 Down 15 Up 15
2. TERMINAL DESCRIPTION
2. TERMINAL DESCRIPTION
 Down calls starting at ground oor level and below are internally converted to up calls. The position of the ground oor is determined by setting the number of basements;
refer to section 5. For instance if there are no basements, then the ground oor is on the rst level and consequently Down 0 call will be internally interpreted as an Up 0 call.
 Although this is not a call, it is listed with the calls for convenience.
10
