S-Lighting S-3 - Product Information; Technical Specifications

S-LIGHTING S-3 www.slservice.pl 4
Power supply voltage: 100-240V
Power consumption: 300W
Voltage frequency: 50/60Hz
Diode type and power: RGB 3in1 LED
Number of diodes: 324pcs
Brightness: 15'000 lm
Beam angle: 140°
Scan rate: 7000 Hz
Dimming: 16-bit dimmer
DMX standard: DMX 512
DMX channels: 1/3/4/6/7/16
AC IN: powerCON
AC OUT: powerCON
DMX IN: XLR - 3 pin
DMX OUT: XLR - 3 pin
IP Rating: IP20
Cooling: Passive
Height [cm]: 20
Width [cm]: 34
Depth [cm]: 10
Weight [kg]: 2.8
3. Product InformatIon
3.1 SPecIfIcatIon
- CAUTION: This product’s housing may be hot when lights
are operating.
- DO NOT connect this product to a dimmer or rheostat.
In case of a serious operating problem stop using this product
immediately!
Important:
Damages caused by a disregard of this user manual are not subject
to warranty or any liability.
