3.5 TESTING BATTERY
3.5.1 Connect the black test lead to the COM jack
and the red test lead to the V/Ω jack.
3.5.2 Set the rotary switch at the desired “BAT”
range position and connect test leads across the
battery.
Position 1.5v 6v 9v
load 27Ω 68Ω 100Ω
3.6 TESTING Telephone Line (RJ11)
3.6.1 Connect the RJ11 test jack to one end of the
telephone line to be tested.
3.6.2 Connect the UAX(Telephone Unit Automatic
Exchange) to the other end of the line.
3.6.3 Push “TEST” button to perform test.
3.7 TESTING Network Cable (RJ45)
● The network tester is suitable for T168A, T568B,
10Base-T and Token Ring.
The Network Cable Tester will check a fault
CAUTION! DO NOT use on the circuits as it
may damage the tester.
