4. SPECIFICATIONS
Accuracy is specified for a period one year after
calibration and at 18 ºC to 28 ºC ( 64 ºF to 82 ºF)
with relative humidity to 80 %.
4.1 GENERAL
4.2 VOLTAGE
DC VOLTAGE
Range
Resolution
Accuracy
200mV
0.1mV
2V 1mV
20V 10mV
200V 100mV
± 0.8 % of rdg ± 2 digits
1000V 1V ± 1.2 % of rdg ± 3 digits
MAXIMUM VOLTAGE 1000V DC or 700V AC
FUSE PROTECTION mA: F 200mA/250V 10A: no
POWER SUPPLY 9V battery, NEDA 1604 or 6F22
OPERATING TEMPERATURE
0 ºC to 40 ºC (32 ºF to 104 ºF)
STORAGE TEMPERATURE — 10 ºC to 50 ºC (14 ºF to 122 ºF)
DIMENSION 185×85×44 mm
WEIGHT 360g (including battery )
- 13-
