S-line VA16 - 4.3 CURRENT

AC VOLTAGE
Range
Resolution
Accuracy
200mV
0.1mV ± 1.2 % of rdg ± 3digits
2V 1mV
20V 10mV
200V 100mV
± 0.8 % of rdg ±3 digits
700V 1V ± 1.2 % of rdg ± 5 digits
Input Impedance: 10MΩ
Frequency Range: 40Hz to 400Hz (for AC)
Response : Average, calibrated in rms of sine
wave
4.3 CURRENT
DC CURRENT
Range Resolution
Accuracy
200µA 0.1µA
2mA 1µA
20mA 10µA
±0.8 % of rdg ± 3digits
200mA 100µA ±1.5 % of rdg ± 2digits
10A 10mA ±2.0 % of rdg ± 5 digits
- 14-
