S-line VA16 - 4.4 RESISTANCE

AC CURRENT
Range Resolution
Accuracy
200µA 0.1µA ±2.0 % of rdg ± 3 digits
2mA 1µA
20mA 10µA
±1.0 % of rdg ± 3 digits
200mA 100µA ±1.8 % of rdg ± 3 digits
10A 10mA ±3.0 % of rdg ± 5digits
Overload Protection: F 200mA/250V fuse for
200µA to 200mA ranges
Frequency Range: 40Hz to 400Hz (for AC)
Response: Average, Calibrated in rms of sine
wave
4.4 RESISTANCE
Range Resolution
Accuracy
200Ω 0.1Ω ± 0.8 % of rdg ± 3 digits
2KΩ 1Ω ± 0.8 % of rdg ± 2 digit
20KΩ 10Ω ± 0.8 % of rdg ± 2 digit
200KΩ 100Ω ± 0.8 % of rdg ± 2 digit
2MΩ 1KΩ ± 0.8 % of rdg ± 2 digit
20MΩ 10KΩ ± 1.0 % of rdg ± 2 digit
200MΩ
100KΩ ± 5.0 % of (rdg-10digits)
± 10 digits
Maximum Open Circuit Voltage: 700mV (3V for
