3
ROGUE2 PARTS LIST
Before getting started check to make sure that all of the parts listed below arrived with the S.R. Smith
ROGUE2
slide.
Ref # *
PART #
DESCRIPTION
QTY
1
05-773
Garden Hose Adapter (ref. pg 13)
1ea.
2
05-181
1” PVC 90 Elbow ST SCH 40 SXS
1 ea.
3
05-767
Plastic Pipe Clamp for 1” SCH 40
6 ea.
4
05-770
PVC Ball Valve SCH 80 SXS
1 ea.
5
05-31-151
¼-20 x 6” Carriage Bolt S/S
4 ea.
6
05-31-149
¼-20 x 8” Carriage Bolt S/S
2 ea.
7
01-212
Aluminum Handrail Spacer
6 ea.
8
6-123
Nylon Handrail Connector
8 ea.
9
6-121
Nylon Tube Connector
6 ea.
10
05-14-111
1/4 x 5/8 Flat Washer
13 ea.
11
5-149
¼” Lock Washer S/S
8 ea.
12
5-137
¼-20 Hex Nut S/S
8 ea.
13
01-210
Aluminum Ladder Spacer
2 ea.
14
5-237
3/8-16 X 5" B.H.C.S. 18-8 S/S FULL-THREAD (TT)
2 ea.
15
5-248
HHCS 3/8-16 X 3.5" S/S
2 ea.
16
5-250
3/8” x 3.5” Button Head Cap Screw S/S
4 ea.
17
5-145
3/8” Flat Washer S/S
16 ea.
18
5-151
3/8” Lock Washer S/S
8 ea.
19
5-139
3/8” Hex Nut S/S
4 ea.
20
5-156
3/8-16 ACORN NUT 316 S/S HIGH Crown
4 ea.
21
05-31-110S
5/16 Hex Washer Head Tek Screw S/S
4 ea.
22
5-371
Self Tapping Screw #10-16 x 1” S/S
6 ea.
23
05-668
Vinyl Cap .172 ID x .5 LG.
6 ea.
24
05-14-124
¼” X ½” Sheet Metal Screw
5 ea.
*
05-786-8
Hose PVC Flex, 8 ft (not shown in Figure 1)
8 ft.
