Specifications
Radiol Amplifier Specifications
General -
Power Supply Voltage ... 14.4 V (10.8 to 15.6 V
allowable)
Current Consumption -
Accessory ............................ less than 15 amps
Back-up ........................
, ........ Iess than 3 amps
Audio Section -
*Tone Action ...................... ± 10 dB at 100 Hz;
±
10
dB at
10kHz
Power Output (Front) .........
25
watts x 2 at max
power output
FM
Section -
Frequency Range ................. 87.9 - 107.9 MHz
*Usable Sensitivity .................................. 12 dBf
*50db Quieting Sensitivity ...................... 18 dBf
*capture Ratio ....................................... 1
.5
dB
*A!ternate Channel Selectivity .................
70
dB
*Stereo Separation .................... 27
dB
@ 1 kHz
*Frequency Response ......
60
- 15k Hz +/- 3 dB
AM
Section-
Frequency Range .................... 530 -
1710kHz
Usable Sensitivity (20dB S/N) .................
28j!v
---------------------
- - -
-----
---
-
--
- - -
Weather Band Section -
Frequency Range ............. 162.4 - 162.55 MHz
Usable Sensitivity ..................................... 5 dBf
Image Rejection Ratio .............................
30 dB
Signal to Noise Ratio .............................. 45 dB
Tape Section -
Tape Speed ..................................... .4.76 cm/s
WOW And Flutter ...................... 0.07% WRMS
*Signal
to Noise Ratio:
Standard Tape (120
ps)
..............
53
dB/
61
dB
(Dolby B NR off/on)
53
dB/
69
dB
... (Dolby
C
NR
off/on)
Chrome Tape(70
ps) ..................
56
dB/ 64 dB
(Dolby
C NR off/on)
56
dB/ 72 dB
... (Dolby B
NR
off/on)
*Stereo Separation ................................ .45 dB
*Frequency Response ......
50 - 14kHz +/- 3 dB
--/1
Specifications 39
Specifications subject to design change.
*Marks
comply
with
AD-HOC
committee
.standards
Dolby noise reduction manufactured under
license
from
DolbyLaboratories
Licensing
Corporation.
"Dolby"
and
the
double-D
symbols
are
trademarks of Dolby Laboratories Licensing
Corporation.
2"(50
mm)
I
1
~
7·7/16"
1189
mm)
.1
LJ
2·5/16"
(59
mm)
To Next Page
