SAB ELLIPSE 2GR - Description of External Components

Manuale Utente – User manual – Gebrauchsanleitung - Macchina caffè modello ELLIPSE
ed 2011 – Pag. 18 di 41
Con riserva di modifica - Specification subject to change – Änderung vorbehalten
Description of external components
Ellipse 3 group automatic
Fig. 1 –
1) Steam tap
2) Steam wand : Caution: This component can become extremely hot and cause burns
3) Hot water wand : Caution: This component can become extremely hot and cause burns
4) Hot water and cup warmer touch pad
5) Touch pad
6) Display
7) Sight glass
8) Emergency switch
9) Coffee brewing group : Caution: This component can become extremely hot and cause burns
10) Filter holder : Caution: This component can become extremely hot and cause burns
11) Drip tray
12) Double gauge
