REPLACING THE ACTIVATED CHARCOAL FILTER
• Open the front panels pulling them downwards�
• Remove the metal grease lters
• Remove the saturated activated charcoal lter�
• Fit the new lters�
• Replace the metal grease lters�
• Close the front panel
Lighting
Dismantle LED light module
Max
Power
Voltage Picture Lamp
Cap
ILCOS D
code
Round/
Diameter
: 70mm
1�5W DC 12 V —— DSR-
1�5-S-70
CHANGING THE LIGHT BULB
The lights are energy ecient, long life LEDs� Therefore, they
should not need replacing throughout the life of the product� In
the unlikely event it does fail then it will need to be replaced by a
qualied engineer�
37
GB
REMOVE
REMOVE
FIX
FIX
