Saba TGV60N3F/C - Electrical Connection and Wiring

39
GB
When the power cord is damaged it must be replaced by the
manufacturer to produce, customer service agent or similarly
qualied personnel.
WIRING DIAGRAM
• This appliance must be earthed.
• This appliance is designed to be connected to a
supply 220-240V, 50Hz-60Hz.
• The wires in the mains lead are coloured in accordance with the
following code;
– Green/yellow = Earth
– Blue = Neutral
– Brown = Live
Electrical Connection
• The wire which is coloured green and yellow
must be connected to the terminal which is
marked with the letter E or by the earth symbol.
AC electricity
Switch 3
Switch 1
Switch 2
AC INPUT
IGNITION
L
E
N
