Sabaj A20a - Display Interface and Instructions

A20a
Display Interface and Instructions
Display
Remote window
Knob
SW OUT
RCA input
XLR input
Power output（DC 15V）
Left Speaker
Right Speaker
Power input（AC IN 100~240V）
NOTE
6
7
8
9
1
2
3
4
5
10
Note:
The 15VDC output of this machine is specially matched with the decoder A20d
. It is not recommended to supply power to other electrical appliances, and this
interface can not be used as power input!
1
H IGH RE SOL U TIO N A MPL IFI ER
A20a
SPEAK ERS OUT
R L
15V DC OUTPU TSW
I NPUTR
L
L
R
AC IN 100~24 0V
2 3 4 5
6
7
8 9 10
