Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
008831 en 2022.02
91/175
Technical data
Oil separator OHU 04136
Compressor type 3 HH
Width
mm *
Length
mm
Height
mm
Max. net.
weight
kg.*
SAB 193 OHU 04136 1700 3660 2100 3800
SAB 233 OHU 04136 1700 3660 2200 4400
SAB 283 S OHU 04136 1700 3660 2300 5200
Table 16: Unit dimension data
Oil separator OHU 04136
Compressor type 4 HH
Width
mm *
Length
mm
Height
mm
Max. net.
weight
kg.*
SAB 233 OHU 04136 1800 3660 2200 4800
SAB 283 S OHU 04136 1800 3660 2300 5500
Table 17: Unit dimension data
* Suction stop valve not included
External heat surface (m
2
)
OHU 04123/2719
5.4 m
2
OHU 04136/3231 10.2 m
2
Table 18
* Excluding motor oil and water
For more exact data, see Compressor units with oil separator OHU 04136 in subsection
7.25 or get the data from COMP1.
