Battery
To change the battery, pull open the compartment on the side of the unit.
Outboard Bass Preamp / DI
SBP-1
Warwick GmbH & Co Music Equipment KG · Gewerbepark 46 · D-08258 Markneukirchen
www.sadowskybass.de | info@sadowskybass.de | www.w-distribution.de
SPECIFICATIONS
Frequency response . . . . . . . . . . . . . 50 Hz - 50 kHz
Battery life ...................... up to 50 hours
Bass control .....................+ 18 dB boost at 40 Hz
Treble control ...................+ 18 dB boost at 4 kHz
Total harmonic distortion ........ 0.1% at 1 kHz
Input impedance ................870 k - 1 Mohm
Output impedance
XLR Out................. 600 ohms
Tuner Out............... 1 kohm
6.3 mm / /" Out . . . . . . . . 12 kohms
Bypass .......................... True Bypass
Current draw . . . . . . . . . . . . . . . . . . . . 11 mA
Power ...........................9V DC (battery or optional power supply)
Dimensions ..................... 106 x 107 x 61 mm / 4.17" x 4.21" x 2.4"
Weight .......................... 780 g / 1.72 lbs
