Saeco Odea Go Service Manual

Saeco International Group Talea / Odea - Line
nternational Group Talea / Odea - Line
Table of contents
Page
4. Functional principles
4.11 Water level detection of fresh water tank 10
4.12 Limescale fi lter 10
4.13 Water level detection of residual water tray 11
4.14 “Empty dreg drawer” message 11
4.15 Descaling request 12
4.16 Electronical confi guration (DIP-switch setting) 12
4.17 Cup lift 13
4.18 Milk Island 13
5. Service modality
5.1.1 Test mode - Talea Giro and Odea 1
5.1.2 Special function mode - Talea Giro and Odea 2
5.2.1 Test mode - Talea Ring and Ring Plus 3
5.2.2 Diagnosis menu - Talea Ring and Ring Plus 6
5.3.1 Test mode - Talea Touch 9
5.3.2 Diagnosis menu - Talea Touch 13
5.4 Error messages 17
6. Standard controls
6.1 Repair plan 1
6.2 Service plan 1
6.3 Final control 2
7. Disassembly
7.1 SBS / dispenser 1
7.2 Housing 1
7.3 Electronics 3
7.4 Boiler pin 3
7.5 Gear motor device 4
7.6 Boiler 5

Saeco Odea Go Specifications

General

Water Tank Capacity	1.5 L
Pump Pressure	15 bar
Number of Coffee Strengths	3
Adjustable Coffee Quantity	Yes
Coffee Input	Coffee Beans, Ground Coffee
Milk Frother	Pannarello
