MAINTENANCE OF THE PRODUCT
PRODUCT SPECIFICATION
1. Keep the place around in handpiece clean from dust and grindings.
2. Remove dust on handpiece with alcohol and avoid humidity around.
- Do not apply the oil and water to the product.
- The grease inside of the bearing could melt away due to the oil.
3. Air cleaning is acceptable but air pressure may affect the handpiece or motor.
4. Store the product as condition a bur is fixed at the collet chuck.
Take out the fuse box and replace the fuse. After that, put it back at the right place.
- AC 100-120 V: 5 A Fuse
- AC 220-240 V: 2 A Fuse
■ Fuse Replacement
■ Control Box
■ Handpiece
Model Name
Input
Fuse
Power Consumption
Maximum Load Current
Model Name
Max. RPM
Torque
Bur Replacement Type
Bur Dimension
Motor Type
FORTE 300Ⅱ
40,000 rpm
4 N·cm
Collet Chuck Type
Φ2.35 mm
BLDC Type
Model Name
Max. RPM
Torque
Bur Replacement Type
Bur Dimension
Motor Type
FORTE 100αⅢ
50,000 rpm
7.8 N·cm
Collet Chuck Type
Φ2.35 mm
BLDC Type
Model Name
Max. RPM
Torque
Bur Replacement Type
Bur Dimension
Motor Type
FORTE 400αⅠ
50,000 rpm
6.5 N·cm
Collet Chuck Type
Φ2.35 mm
BLDC Type
FORTE 300
AC 100 V, 50/60 Hz
AC 110-120 V, 50/60 Hz
AC 100-120 V, 5A
AC 220-240 V, 2A
230 W
2 A
FORTE 300α FORTE 300αD
Fuse Box
AC 220-230 V, 50/60 Hz
AC 240 V, 50/60 Hz
