SAFTRONICS
2
2.0 SPECIFICATIONS
· Power
Single phase 120 or 240 vac, 50/60 Hz., (±10%).
· Speed range
10:1 with armature feedback, 50:1 with tachometer feedback.
· Load regulation
±3% with armature voltage, (±10% line voltage change).
· Acceleration/Deceleration
Adjustable: 0.1-30 seconds from 0 to full speed.
· Temperature range
32°F - 104°F (0-40°C).
· Altitude
2000 feet (600m) maximum without derating.
· Rectifier configuration
The DG2 PLUS employs a single phase, half-wave bridge.
· HP & Current rating
MODEL
HP AMPS
120 VAC 240 VAC INPUT OUTPUT
DG2P-10 1 2 18 10
DG2P-15 - 3 25 15
DG2P-25 - 5 34 25
· Voltage rating (selectable via JMP1, see P.5.)
INPUT
OUTPUT VDC
ARMATURE FIELD
120 VAC 0-90 50/100
240 VAC 0-180 100/200
· Short circuit rating
Suitable for use on a circuit capable of delivering not more than 5000
rms symmetrical amperes, 240 V maximum.
2.1 Electical
