SAFTRONICS
6
Before applying power, refer to section 6.0 and ensure that all control
and power wiring is correct, the power source, motor, and drive are
matched, and that all links are properly set. Turn the speed pot to the
zero reference position and ensure that the run circuit is disabled.
1. Measure and confirm that the AC supply voltage is correct
according to the table on page 2. Confirm that the field voltage is
correct according to the motor nameplate. Apply power and
observe that LED1 "POWER" is illuminated.
2. Press the "START" pushbutton. Observe that LED2, "RUN", is
illuminated and that the motor does not rotate. To set minimum
speed, slowly increase RV7 until the motor reaches the desired
speed. The external speed reference should be set at zero.
3. With the speed reference set at maximum, the motor should rotate
at rated speed and/or voltage. If not, adjust RV6 for the correct
setting.
4. If the acceleration and deceleration rates are not suitable, see section
2.4, p.3, for adjustment.
4.3 Starting
